Robertshaw 9520 DIGITAL NON-PROGRAMMABLE Thermostat Manual
IMPORTANT SAFETY INFORMATION
WARNING:
- Always turn off power at the main power source by unscrewing fuse or switching circuit breaker to the OFF position before installing, removing, cleaning, or servicing thermostat.
- Read all of the information in this manual before installing or pro- gramming this thermostat
- This is a 24V AC low-voltage thermostat. Do not install on voltages higher than 30V AC.
- All wiring must conform to local and national building and electrical codes and ordinances.
- Do not short (jumper) across terminals on the gas valve or at the system control to test installation. This will damage the thermostat and void the warranty
Robertshaw 9520 Features
- Multi-stage heating and cooling control
- Zone system compatible as a master thermostat
- Multi-colored LED indicators for system status
- Low battery indicator.
- Fahrenheit/Celsius display option.
- Adjustable from 45°F (4°C) to 90°F (32°C).
- Accuracy within ± 1 degree.
- Adjustable temperature differential: 1-3 degrees F.
- Automatic heating shutdown if temperature exceeds 90°F (32(C).
Robertshaw 9520 Installation
Step 1: Replacing Existing Thermostat
- Turn off power to heating and cooling system.
- Remove cover of old thermostat to expose wires. (Figure 1)
-
Disconnect wires one at a time from existing terminals. USE ENCLOSED LABELS TO MARK EXISTING WIRES. Refer to cross refer- ences in Table 1 if existing wiring does not directly match the labels.
-
If you have any questions about cross referencing the old terminal to the new label, reference your equipment installation manual, a licensed contractor, or call Robertshaw Tech Support (800) 445-8299
-
-
Remove existing thermostat base from wall.
Table 1
|
Old Terminal |
New Label |
Description |
|
R, V-VR or VR-R |
R |
24 VAC Return |
|
Y, Y1 or M |
Y |
Stage 1 Cooling/Heating Circuit |
|
O or R |
O |
Reversing Valve (Cooling Mode) |
|
B |
B |
Reversing Valve (Heating Mode) |
|
F or G |
G |
Fan Control Relay |
|
Y2 |
Y2 |
2nd Stage Cooling Circuit |
|
W1 or W2 or W-U |
W2 |
2nd Stage Heating Control |
|
L or X |
L |
System Monitor LED |
|
E |
E |
Emergency Heating Circuit |
|
C, X or B |
C |
24 VAC Transformer Common Side |
Step 2: Installing Model 9520 Thermostat
NOTE: FOR NEW INSTALLATIONS, MOUNT THERMOSTAT ON INSIDE WALL, 4-5 FEET ABOVE THE FLOOR. DO NOT INSTALL BEHIND A DOOR, IN A CORNER, NEAR AIR VENTS, IN DIRECT SUNLIGHT, OR NEAR ANY HEAT OR STEAM GENERATING FIXTURES. INSTALLATION AT THESE PLACES WILL AFFECTS THERMOSTAT OPERATION.
- Turn off power to the heating and cooling systems.
- Place COOL-OFF-HEAT-EM
- Place AUTO-ON switch into AUTO position.
- Remove the cover using a coin or screwdriver
.png)
- location. Make surewires will feed through opening on base of thermostat.
- Mark placement of mounting holes. See Figure 3. Set base aside.
- Drill the marked holes using a 3/16" drill bit. NOTE: Enclosed plastic anchors do not require a drilled hole for drywall.
- Tap plastic anchors into the wall.
- Align base with plastic anchors and feed wires through opening.
- Secure base to wall with supplied screws.
- Terminal screws are loosened. Insert wires into terminal strip (Figure 4) matching the label to the corresponding terminal (see Wiring Diagrams below). Tighten screws.
