HP LaserJet 4200/4250/4300/4350 series Printers Service Manual

Printer HP LaserJet 4200/4250/4300/4350 series configurations

The HP LaserJet 4200, 4250, 4300 and 4350 Series printers are available in a total of six models

Base model Availability Configuration

HP LaserJet 4200 printer (Q2425A)

  • 48 MB RAM, expandable to 416 MB
  • One 100-sheet tray and one 500-sheet tray

HP LaserJet 4200L printer (Q3993A) (This model is not available in all countries/regions.)

  • 48 MB RAM, expandable to 288 MB
  • One 100-sheet tray and one 500-sheet tray

HP LaserJet 4250 printer (Q5400A)

  • 48 MB RAM, expandable to 512 MB
  • One 100-sheet tray and one 500-sheet tray

HP LaserJet 4300 printer (Q2431A)

  • 4 MB RAM, expandable to 416 MB
  • One 100-sheet tray and one 500-sheet tray



n model Availability Configuration

HP LaserJet 4200n printer (Q2426A)

  • 64 MB RAM, expandable to 416 MB
  • One 100-sheet tray and one 500-sheet tray
  • HP Jetdirect 10/100Base-TX print server for network connection

HP LaserJet 4200Ln printer (Q3994A)

  • 64 MB RAM, expandable to 416 MB
  • One 100-sheet tray and one 500-sheet tray
  • HP Jetdirect 10/100Base-TX print server for network connection

HP LaserJet 4250n printer (Q5401A)

  • 64 MB RAM, expandable to 512 MB
  • One 100-sheet tray and one 500-sheet tray
  • HP Jetdirect embedded print server for connecting to a 10/100Base-TX network

HP LaserJet 4300n printer (Q2432A)

  • 80 MB RAM, expandable to 416 MB
  • One 100-sheet tray and one 500-sheet tray
  • HP Jetdirect 10/100Base-TX print server for network connection

HP LaserJet 4350n printer (Q5407A)

  • 80 MB RAM, expandable to 512 MB
  • One 100-sheet tray and one 500-sheet tray
  • HP Jetdirect embedded print server for connecting to a 10/100Base-TX network

tn Model Availability Configuration

HP LaserJet 4200tn Printer (Q2427A)

  • 64 MB RAM, expandable to 416 MB
  • One 100-sheet tray and two 500-sheet trays
  • HP Jetdirect 10/100Base-TX print server for network connection

HP LaserJet 4250tn printer (Q5402A)

  • 64 MB RAM, expandable to 512 MB
  • One 100-sheet tray and two 500-sheet trays
  • HP Jetdirect embedded print server for connecting to a 10/100Base-TX network

HP LaserJet 4300tn printer (Q2433A)

  • 80 MB RAM, expandable to 416 MB
  • One 100-sheet tray and two 500-sheet trays
  • HP Jetdirect 10/100Base-TX print server for network connection

HP LaserJet 4350tn printer (Q5408A)

  • 80 MB RAM, expandable to 512 MB
  • One 100-sheet tray and two 500-sheet trays
  • HP Jetdirect embedded print server for connecting to a 10/100Base-TX network

Show HP LaserJet 4200/4250/4300/4350 series Service Manual on PDF Below

HP LaserJet 4200-4250-4300-4350 series Service Manual
